2017 Ford F-350 in Canada - Canadian Prices, Trims, Specs, Photos, Recalls

1 of 89

2WD Reg Cab 145" WB 60" CA XL

$39,749 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,439 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

2 of 89

2WD Reg Cab 145" WB 60" CA XL

$40,999 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,666 kg

Dead Weight Hitch - Max Tongue Wt.

767 kg

Wt Distributing Hitch - Max Trailer Wt.

7,666 kg

Wt Distributing Hitch - Max Tongue Wt.

767 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,620 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,666 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

3 of 89

2WD Reg Cab 169" WB 84" CA XL

$41,599 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,575 kg

Dead Weight Hitch - Max Tongue Wt.

757 kg

Wt Distributing Hitch - Max Trailer Wt.

7,575 kg

Wt Distributing Hitch - Max Tongue Wt.

757 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,575 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,293 mm

Length, Overall

6,472 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

4 of 89

2WD Reg Cab 142" XL

$41,849 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,942 kg

Dead Weight Hitch - Max Tongue Wt.

594 kg

Wt Distributing Hitch - Max Trailer Wt.

5,942 kg

Wt Distributing Hitch - Max Tongue Wt.

594 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,897 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,942 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

5 of 89

2WD Reg Cab 142" XL

$43,099 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,987 kg

Dead Weight Hitch - Max Tongue Wt.

599 kg

Wt Distributing Hitch - Max Trailer Wt.

5,987 kg

Wt Distributing Hitch - Max Tongue Wt.

599 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,942 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,987 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

6 of 89

4WD Reg Cab 145" WB 60" CA XL

$43,249 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

7 of 89

2WD SuperCab 168" WB 60" CA XL

$43,449 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,303 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,989 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

8 of 89

2WD Reg Cab 145" WB 60" CA XLT

$44,349 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,439 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

9 of 89

4WD Reg Cab 145" WB 60" CA XL

$44,499 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,439 kg

Dead Weight Hitch - Max Tongue Wt.

744 kg

Wt Distributing Hitch - Max Trailer Wt.

7,439 kg

Wt Distributing Hitch - Max Tongue Wt.

744 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,394 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,439 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

10 of 89

2WD SuperCab 168" WB 60" CA XL

$44,699 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,484 kg

Dead Weight Hitch - Max Tongue Wt.

748 kg

Wt Distributing Hitch - Max Trailer Wt.

7,484 kg

Wt Distributing Hitch - Max Tongue Wt.

748 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,484 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,994 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

11 of 89

2WD SuperCab 148" XL

$44,949 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,851 kg

Dead Weight Hitch - Max Tongue Wt.

585 kg

Wt Distributing Hitch - Max Trailer Wt.

5,851 kg

Wt Distributing Hitch - Max Tongue Wt.

585 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,806 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,851 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,759 mm

Length, Overall

6,050 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,986 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

12 of 89

4WD Reg Cab 169" WB 84" CA XL

$45,099 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,394 kg

Dead Weight Hitch - Max Tongue Wt.

739 kg

Wt Distributing Hitch - Max Trailer Wt.

7,394 kg

Wt Distributing Hitch - Max Tongue Wt.

739 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,394 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,293 mm

Length, Overall

6,472 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,055 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

13 of 89

2WD Crew Cab 179" WB 60" CA XL

$45,249 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,212 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,991 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

14 of 89

4WD Reg Cab 142" XL

$45,349 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,715 kg

Dead Weight Hitch - Max Tongue Wt.

572 kg

Wt Distributing Hitch - Max Trailer Wt.

5,715 kg

Wt Distributing Hitch - Max Tongue Wt.

572 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,715 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,715 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,055 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

15 of 89

2WD SuperCab 164" XL

$45,549 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,981 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

16 of 89

2WD Reg Cab 145" WB 60" CA XLT

$45,599 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,666 kg

Dead Weight Hitch - Max Tongue Wt.

767 kg

Wt Distributing Hitch - Max Trailer Wt.

7,666 kg

Wt Distributing Hitch - Max Tongue Wt.

767 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,620 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,666 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

17 of 89

2WD Reg Cab 169" WB 84" CA XLT

$46,199 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,575 kg

Dead Weight Hitch - Max Tongue Wt.

757 kg

Wt Distributing Hitch - Max Trailer Wt.

7,575 kg

Wt Distributing Hitch - Max Tongue Wt.

757 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,575 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,293 mm

Length, Overall

6,472 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

18 of 89

2WD Crew Cab 179" WB 60" CA XL

$46,499 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,394 kg

Dead Weight Hitch - Max Tongue Wt.

739 kg

Wt Distributing Hitch - Max Trailer Wt.

7,394 kg

Wt Distributing Hitch - Max Tongue Wt.

739 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,394 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,394 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,996 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

19 of 89

4WD Reg Cab 142" XL

$46,599 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Optional

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

2,047 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

20 of 89

2WD Crew Cab 160" XL

$46,749 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,064 mm

Length, Overall

6,350 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,986 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

21 of 89

2WD SuperCab 164" XL

$46,799 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

22 of 89

4WD SuperCab 168" WB 60" CA XL

$46,949 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,121 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

23 of 89

2WD Crew Cab 176" XL

$47,349 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,670 kg

Dead Weight Hitch - Max Tongue Wt.

567 kg

Wt Distributing Hitch - Max Trailer Wt.

5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

567 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,625 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,670 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,981 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

24 of 89

2WD Reg Cab 142" XLT

$47,849 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,942 kg

Dead Weight Hitch - Max Tongue Wt.

594 kg

Wt Distributing Hitch - Max Trailer Wt.

5,942 kg

Wt Distributing Hitch - Max Tongue Wt.

594 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,897 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,942 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

25 of 89

4WD Reg Cab 145" WB 60" CA XLT

$47,849 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

26 of 89

2WD SuperCab 168" WB 60" CA XLT

$48,049 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,303 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,989 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

27 of 89

4WD SuperCab 168" WB 60" CA XL

$48,199 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,303 kg

Dead Weight Hitch - Max Tongue Wt.

730 kg

Wt Distributing Hitch - Max Trailer Wt.

7,303 kg

Wt Distributing Hitch - Max Tongue Wt.

730 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,303 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

28 of 89

4WD SuperCab 148" XL

$48,449 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,625 kg

Dead Weight Hitch - Max Tongue Wt.

562 kg

Wt Distributing Hitch - Max Trailer Wt.

5,625 kg

Wt Distributing Hitch - Max Tongue Wt.

562 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,625 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,625 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,759 mm

Length, Overall

6,050 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,065 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

29 of 89

2WD Crew Cab 176" XL

$48,599 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,670 kg

Dead Weight Hitch - Max Tongue Wt.

567 kg

Wt Distributing Hitch - Max Trailer Wt.

5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

567 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,670 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,670 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

30 of 89

4WD Crew Cab 179" WB 60" CA XL

$48,749 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,031 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/70SR18 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

31 of 89

4WD SuperCab 164" XL

$49,049 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,579 kg

Dead Weight Hitch - Max Tongue Wt.

558 kg

Wt Distributing Hitch - Max Trailer Wt.

5,579 kg

Wt Distributing Hitch - Max Tongue Wt.

558 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,579 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,579 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

32 of 89

2WD Reg Cab 142" XLT

$49,099 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,987 kg

Dead Weight Hitch - Max Tongue Wt.

599 kg

Wt Distributing Hitch - Max Trailer Wt.

5,987 kg

Wt Distributing Hitch - Max Tongue Wt.

599 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,942 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,987 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,984 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

33 of 89

XLT 4WD Reg Cab 145" WB 60" CA

$49,099 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,439 kg

Dead Weight Hitch - Max Tongue Wt.

744 kg

Wt Distributing Hitch - Max Trailer Wt.

7,439 kg

Wt Distributing Hitch - Max Tongue Wt.

744 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,394 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,439 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,683 mm

Length, Overall

5,860 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

34 of 89

2WD SuperCab 168" WB 60" CA XLT

$49,299 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,484 kg

Dead Weight Hitch - Max Tongue Wt.

748 kg

Wt Distributing Hitch - Max Trailer Wt.

7,484 kg

Wt Distributing Hitch - Max Tongue Wt.

748 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,484 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,994 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

35 of 89

4WD Reg Cab 169" WB 84" CA XLT

$49,699 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,394 kg

Dead Weight Hitch - Max Tongue Wt.

739 kg

Wt Distributing Hitch - Max Trailer Wt.

7,394 kg

Wt Distributing Hitch - Max Tongue Wt.

739 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,394 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,293 mm

Length, Overall

6,472 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,055 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

36 of 89

2WD Crew Cab 179" WB 60" CA XLT

$49,849 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,212 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,991 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

37 of 89

4WD Crew Cab 179" WB 60" CA XL

$49,999 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,212 kg

Dead Weight Hitch - Max Tongue Wt.

721 kg

Wt Distributing Hitch - Max Trailer Wt.

7,212 kg

Wt Distributing Hitch - Max Tongue Wt.

721 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,167 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,212 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

38 of 89

4WD Crew Cab 160" XL

$50,249 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,579 kg

Dead Weight Hitch - Max Tongue Wt.

558 kg

Wt Distributing Hitch - Max Trailer Wt.

5,579 kg

Wt Distributing Hitch - Max Tongue Wt.

558 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,534 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,579 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,064 mm

Length, Overall

6,350 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,065 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

39 of 89

4WD SuperCab 164" XL

$50,299 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,579 kg

Dead Weight Hitch - Max Tongue Wt.

558 kg

Wt Distributing Hitch - Max Trailer Wt.

5,579 kg

Wt Distributing Hitch - Max Tongue Wt.

558 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,579 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,579 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

2,055 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

40 of 89

4WD Crew Cab 176" XL

$50,849 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,443 kg

Dead Weight Hitch - Max Tongue Wt.

544 kg

Wt Distributing Hitch - Max Trailer Wt.

5,443 kg

Wt Distributing Hitch - Max Tongue Wt.

544 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,443 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,443 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,060 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT275/70SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

41 of 89

2WD SuperCab 148" XLT

$50,949 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,851 kg

Dead Weight Hitch - Max Tongue Wt.

585 kg

Wt Distributing Hitch - Max Trailer Wt.

5,851 kg

Wt Distributing Hitch - Max Tongue Wt.

585 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,806 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,851 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,759 mm

Length, Overall

6,050 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,986 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

42 of 89

2WD Crew Cab 179" WB 60" CA XLT

$51,099 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,394 kg

Dead Weight Hitch - Max Tongue Wt.

739 kg

Wt Distributing Hitch - Max Trailer Wt.

7,394 kg

Wt Distributing Hitch - Max Tongue Wt.

739 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,394 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,394 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,996 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

43 of 89

4WD Reg Cab 142" XLT

$51,349 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,715 kg

Dead Weight Hitch - Max Tongue Wt.

572 kg

Wt Distributing Hitch - Max Trailer Wt.

5,715 kg

Wt Distributing Hitch - Max Tongue Wt.

572 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,715 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,715 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,055 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70SR18 LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT275/70SR18 LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

44 of 89

2WD SuperCab 164" XLT

$51,549 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,981 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

45 of 89

4WD SuperCab 168" WB 60" CA XLT

$51,549 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,121 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

46 of 89

4WD Crew Cab 176" XL

$52,099 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,488 kg

Dead Weight Hitch - Max Tongue Wt.

549 kg

Wt Distributing Hitch - Max Trailer Wt.

5,488 kg

Wt Distributing Hitch - Max Tongue Wt.

549 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,488 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,488 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Optional

Satellite Radio

Optional

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Optional

Multi-Zone Air Conditioning

Optional

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

2,057 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

47 of 89

4WD Reg Cab 142" XLT

$52,599 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,607 mm

Length, Overall

5,888 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

2,047 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

48 of 89

2WD Crew Cab 160" XLT

$52,749 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,064 mm

Length, Overall

6,350 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,986 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

49 of 89

2WD SuperCab 164" XLT

$52,799 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,761 kg

Dead Weight Hitch - Max Tongue Wt.

576 kg

Wt Distributing Hitch - Max Trailer Wt.

5,761 kg

Wt Distributing Hitch - Max Tongue Wt.

576 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,761 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,761 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

128.7 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,166 mm

Length, Overall

6,462 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

50 of 89

4WD SuperCab 168" WB 60" CA XLT

$52,799 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

7,303 kg

Dead Weight Hitch - Max Tongue Wt.

730 kg

Wt Distributing Hitch - Max Trailer Wt.

7,303 kg

Wt Distributing Hitch - Max Tongue Wt.

730 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

7,303 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,267 mm

Length, Overall

6,434 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

51 of 89

2WD Crew Cab 176" XLT

$53,349 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,670 kg

Dead Weight Hitch - Max Tongue Wt.

567 kg

Wt Distributing Hitch - Max Trailer Wt.

5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

567 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,625 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,670 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

1,981 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

52 of 89

4WD Crew Cab 179" WB 60" CA XLT

$53,349 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

330 - 385 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

330 hp @ 2600 rpm 385 hp @ 5750 rpm

Torque

750 ft-lb @ 2000 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

6,123 kg

Dead Weight Hitch - Max Tongue Wt.

612 kg

Wt Distributing Hitch - Max Trailer Wt.

6,123 kg

Wt Distributing Hitch - Max Tongue Wt.

612 kg

Fifth Wheel Hitch - Max Trailer Wt.

7,031 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

6,123 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

100.0 - 151.4 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Optional

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,547 mm

Length, Overall

6,736 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Rear Tire Size

LT245/75SR17 LT275/70SR18 LT265/70SR17 LT275/65SR18

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

53 of 89

4WD SuperCab 148" XLT

$54,449 MSRP

Flex Fuel, Diesel

Four-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,625 kg

Dead Weight Hitch - Max Tongue Wt.

562 kg

Wt Distributing Hitch - Max Trailer Wt.

5,625 kg

Wt Distributing Hitch - Max Tongue Wt.

562 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,625 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,625 kg

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 - 132.5 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Included

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,024 mm

Rear Leg Room

851 mm

Rear Shoulder Room

1,671 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,759 mm

Length, Overall

6,050 mm

Width, Max w/o mirrors

2,032 mm

Height, Overall

2,065 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70SR18 LT275/65SR20 LT265/70SR17 LT275/65SR18 LT245/75SR17

Rear Tire Size

LT275/70SR18 LT275/65SR20 LT265/70SR17 LT275/65SR18 LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

54 of 89

2WD Crew Cab 176" XLT

$54,599 MSRP

Flex Fuel, Diesel

Rear-Wheel Drive

385 - 440 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Intercooled Turbo Diesel V-8 Regular Unleaded V-8

Displacement

6.7 L/406 6.2 L/379

Fuel System

Diesel Direct Injection Sequential MPI

Horsepower

440 hp @ 2800 rpm 385 hp @ 5750 rpm

Torque

925 ft-lb @ 1800 rpm 430 ft-lb @ 3800 rpm

Dead Weight Hitch - Max Trailer Wt.

5,670 kg

Dead Weight Hitch - Max Tongue Wt.

567 kg

Wt Distributing Hitch - Max Trailer Wt.

5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

567 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,670 kg

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

5,670 kg

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

TorqShift 6-Speed Automatic w/OD -inc: (6R140), SelectShift and tow/haul mode

Fuel

Flex Fuel Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

181.7 - 183.6 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Included

Rear Side Air Bag

Not Available

Front Head Air Bag

Included

Rear Head Air Bag

Included

Knee Air Bag

Not Available

Seatbelt Air Bag

Included

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Included

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Included

Driver Assistance

Back-Up Camera

Included

360 Camera

Not Available

Brake Assist

Included

Blind Spot Monitor

Included

Lane Departure Warning

Included

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Included

Rear Parking Aid

Included

Automatic Parking

Optional

Tire Pressure Monitor

Included

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Included

CD Player

Included

MP3 Player

Included

Auxiliary Audio Input

Included

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Included

Connectivity

Smart Device Integration

Included

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Included

Bluetooth Connection

Included

Power Outlet

Not Available

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Optional

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Included

Variable Speed Intermittent Wipers

Included

Rain Sensing Wipers

Included

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Optional

Interior

Passenger Capacity

5 - 6

Front Head Room

1,036 mm

Front Leg Room

1,115 mm

Front Shoulder Room

1,694 mm

Rear Head Room

1,026 mm

Rear Leg Room

1,107 mm

Rear Shoulder Room

1,674 mm

Trunk Volume

N/A

Front Reading Lamps

Not Available

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,470 mm

Length, Overall

6,761 mm

Width, Max w/o mirrors

2,438 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75SR17

Rear Tire Size

LT245/75SR17

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Optional

Bed Liner

Included

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Included

Engine Immobilizer

Included

Wheels-Locks

Not Available

55 of 89

4WD Crew Cab 179" WB 60" CA XLT

$54,599 MSRP

2017 Ford F-350

Key Specifications for 2017 Ford F-350

Review & Compare:
2017 Ford F-350 Trims

2017 Ford F-350

Key Specifications for 2017 Ford F-350

Review & Compare: 2017 Ford F-350 Trims

Review & Compare:
2017 Ford F-350 Trims
