2006 Ford F-350 in Canada - Canadian Prices, Trims, Specs, Photos, Recalls

1 of 133

Reg Cab 137" XL

$23,200 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

4,128 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

413 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

4,128 - 7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

413 - 771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,951 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

2 of 133

Supercab 142" XL

$25,660 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,963 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

3 of 133

Supercab 158" XL

$25,850 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

4 of 133

Reg Cab 137" XL 4WD

$26,205 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,946 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

395 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,946 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

395 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,052 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

5 of 133

Crew Cab 156" XL

$26,910 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

6 of 133

Crew Cab 172" XL

$27,110 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

7 of 133

Reg Cab 137" XLT

$27,300 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

4,128 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

413 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

4,128 - 7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

413 - 771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,951 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

8 of 133

Reg Cab 141" WB XL

$27,999 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,856 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

386 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,856 - 7,212 kg

Fifth Wheel Hitch - Max Tongue Wt.

386 - 721 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

1,953 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

9 of 133

Supercab 142" XL 4WD

$28,670 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,765 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

376 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,765 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

376 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,068 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

10 of 133

Supercab 158" XL 4WD

$28,865 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,765 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

376 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,765 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

376 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

11 of 133

Reg Cab 137" XL

$29,399 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,951 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

12 of 133

Crew Cab 156" XL 4WD

$29,920 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,674 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

367 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,674 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

367 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,078 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

13 of 133

Crew Cab 172" XL 4WD

$30,115 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,674 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

367 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,674 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

367 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Optional

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Included

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,075 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Rear Tire Size

LT275/65R18E LT275/70R18E LT265/70R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

14 of 133

Reg Cab 137" XLT 4WD

$30,450 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,946 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

395 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,946 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

395 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,052 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R20E LT275/70R18E

Rear Tire Size

LT275/65R20E LT275/70R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

15 of 133

Reg Cab 141" WB XL

$30,499 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,719 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

372 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,719 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

372 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

16 of 133

Supercab 142" XLT

$30,565 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,963 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

17 of 133

Supercab 158" XLT

$30,770 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

18 of 133

Reg Cab 165" WB XL

$30,799 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,719 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

372 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,629 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

363 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,186 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,953 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

19 of 133

Reg Cab 137" XL

$30,999 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,426 mm

Height, Overall

1,948 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

20 of 133

SuperCab 162" WB XL

$31,599 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,719 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

372 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,719 - 7,076 kg

Fifth Wheel Hitch - Max Tongue Wt.

372 - 708 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,110 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

1,966 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

21 of 133

Reg Cab 141" WB XL 4WD

$31,699 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,674 - 5,035 kg

Wt Distributing Hitch - Max Tongue Wt.

367 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,674 - 7,031 kg

Fifth Wheel Hitch - Max Tongue Wt.

367 - 703 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

2,073 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70R18E

Rear Tire Size

LT275/70R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

22 of 133

Supercab 142" XL

$31,999 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

978 mm

Rear Leg Room

798 - 823 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,963 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

23 of 133

Supercab 158" XL

$32,599 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

978 mm

Rear Leg Room

798 - 823 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

24 of 133

Reg Cab 141" WB XLT

$32,699 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,856 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

386 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,856 - 7,212 kg

Fifth Wheel Hitch - Max Tongue Wt.

386 - 721 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

1,953 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

25 of 133

Crew Cab 156" XLT

$32,765 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

26 of 133

Crew Cab 172" XLT

$32,960 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

27 of 133

Supercab 142" Lariat

$33,060 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,963 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

28 of 133

Reg Cab 137" 4WD XL

$33,099 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,052 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/70R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

29 of 133

Supercab 158" Lariat

$33,265 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,992 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

399 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,992 - 7,575 kg

Fifth Wheel Hitch - Max Tongue Wt.

399 - 757 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

30 of 133

Crew Cab 176" WB XL

$33,399 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,629 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

363 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,629 - 6,985 kg

Fifth Wheel Hitch - Max Tongue Wt.

363 - 699 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,475 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

31 of 133

Crew Cab 156" XL

$33,699 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,041 mm

Rear Leg Room

1,039 - 1,049 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

32 of 133

Supercab 142" XLT 4WD

$33,715 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,765 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

376 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,765 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

376 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,068 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R20E LT275/70R18E

Rear Tire Size

LT275/65R20E LT275/70R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

33 of 133

SuperCab 162" WB XL

$33,899 MSRP

Gasoline, Diesel

Rear-Wheel Drive

325 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Turbo Diesel V8 Gas V10

Displacement

6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

6,033 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

603 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

6,033 - 7,167 kg

Fifth Wheel Hitch - Max Tongue Wt.

603 - 717 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,110 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,966 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

34 of 133

Supercab 158" XLT 4WD

$33,910 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,765 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

376 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,765 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

376 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,062 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R20E LT275/70R18E

Rear Tire Size

LT275/65R20E LT275/70R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

35 of 133

Reg Cab 137" XLT

$33,999 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,951 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

36 of 133

Reg Cab 141" WB XLT

$34,099 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,719 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

372 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,719 - 7,348 kg

Fifth Wheel Hitch - Max Tongue Wt.

372 - 735 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,958 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

37 of 133

Reg Cab 141" WB XL 4WD

$34,199 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,538 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

354 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,538 - 7,121 kg

Fifth Wheel Hitch - Max Tongue Wt.

354 - 712 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,576 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

2,032 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

38 of 133

Supercab 158" XL

$34,199 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

978 mm

Rear Leg Room

798 - 823 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,013 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,426 mm

Height, Overall

1,956 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

39 of 133

Crew Cab 172" XL

$34,299 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,711 kg

Fifth Wheel Hitch - Max Tongue Wt.

771 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,041 mm

Rear Leg Room

1,039 - 1,049 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/65R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

40 of 133

Reg Cab 165" WB XLT

$34,399 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,719 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

372 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,629 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

363 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,186 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,953 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

41 of 133

Reg Cab 165" WB XL 4WD

$34,499 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V8 Turbo Diesel V8 Gas V10

Displacement

5.4L/330 6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

300 hp @ 5000 rpm 325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

365 ft-lb @ 3750 rpm 570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,538 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

354 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,447 - 7,031 kg

Fifth Wheel Hitch - Max Tongue Wt.

345 - 703 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,044 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,186 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

2,037 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

42 of 133

Reg Cab 137" 4WD XL

$34,699 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,426 mm

Height, Overall

2,022 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

43 of 133

Reg Cab 137" XLT

$34,899 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 3

Front Head Room

1,049 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

N/A

Rear Leg Room

N/A

Rear Shoulder Room

N/A

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,480 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,426 mm

Height, Overall

1,948 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

44 of 133

Crew Cab 176" WB XL

$35,099 MSRP

Gasoline, Diesel

Rear-Wheel Drive

325 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Turbo Diesel V8 Gas V10

Displacement

6.0L/363 6.8L/415

Fuel System

DI SEFI

Horsepower

325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

5,942 - 6,804 kg

Wt Distributing Hitch - Max Tongue Wt.

594 - 680 kg

Fifth Wheel Hitch - Max Trailer Wt.

5,942 - 7,076 kg

Fifth Wheel Hitch - Max Tongue Wt.

594 - 708 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

72.0 - 151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,475 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,342 mm

Height, Overall

1,979 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

45 of 133

SuperCab 162" WB XL 4WD

$35,299 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Turbo Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

DI SEFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,493 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

349 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,493 - 6,849 kg

Fifth Wheel Hitch - Max Tongue Wt.

349 - 685 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: PTO provision

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

151.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Not Available

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

970 mm

Rear Leg Room

818 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

4,110 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,019 mm

Height, Overall

2,070 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70R18E

Rear Tire Size

LT275/70R18E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

46 of 133

Crew Cab 156" XL

$35,399 MSRP

Gasoline, Diesel

Rear-Wheel Drive

325 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Diesel V8 Gas V10

Displacement

6.0L/363 6.8L/415

Fuel System

Turbo-Charged DI EFI

Horsepower

325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,041 mm

Rear Leg Room

1,039 - 1,049 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,426 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT245/75R17E

Rear Tire Size

LT245/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

47 of 133

Crew Cab 156" Lariat

$35,560 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

48 of 133

Crew Cab 156" King Ranch

$35,560 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

4,354 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

435 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

4,354 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

435 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

Torqshift 5-speed automatic transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

4 - 5

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,976 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

49 of 133

Crew Cab 156" XLT 4WD

$35,670 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,674 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

367 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,674 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

367 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

3,967 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,078 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R20E LT275/70R18E

Rear Tire Size

LT275/65R20E LT275/70R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

50 of 133

Supercab 142" 4WD XL

$35,699 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/363 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

N/A

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

109.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Not Available

Automatic Headlights

Not Available

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Optional

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Not Available

Passenger Adjustable Lumbar

Not Available

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Not Available

Keyless Start

Not Available

Power Driver Seat

Not Available

Power Passenger Seat

Not Available

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Optional

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

2 - 6

Front Head Room

1,052 mm

Front Leg Room

1,034 mm

Front Shoulder Room

1,727 mm

Rear Head Room

978 mm

Rear Leg Room

798 - 823 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Not Available

Exterior

Wheelbase

3,602 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,068 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/70R18E LT265/70R17E LT265/75R17E

Rear Tire Size

LT275/70R18E LT265/70R17E LT265/75R17E

Sun/Moon Roof

Not Available

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

51 of 133

Crew Cab 172" Lariat

$35,755 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,901 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

390 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,901 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

390 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

52 of 133

Crew Cab 172" King Ranch

$35,755 MSRP

Gasoline, Diesel

Rear-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

4,354 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

435 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

4,354 - 7,484 kg

Fifth Wheel Hitch - Max Tongue Wt.

435 - 748 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

Torqshift 5-speed automatic transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Included

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Included

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Included

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Included

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Included

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

4 - 5

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

1,971 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R18E

Rear Tire Size

LT275/65R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

53 of 133

Crew Cab 172" XLT 4WD

$35,865 MSRP

Gasoline, Diesel

Four-Wheel Drive

300 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Gas V10 Diesel V8 Gas V8

Displacement

6.8L/415 6.0L/364 5.4L/330

Fuel System

Turbo-Charged DI EFI

Horsepower

362 hp @ 4750 rpm 325 hp @ 3300 rpm 300 hp @ 5000 rpm

Torque

457 ft-lb @ 3250 rpm 570 ft-lb @ 2000 rpm 365 ft-lb @ 3750 rpm

Dead Weight Hitch - Max Trailer Wt.

2,268 kg

Dead Weight Hitch - Max Tongue Wt.

227 kg

Wt Distributing Hitch - Max Trailer Wt.

3,674 - 5,670 kg

Wt Distributing Hitch - Max Tongue Wt.

367 - 567 kg

Fifth Wheel Hitch - Max Trailer Wt.

3,674 - 7,257 kg

Fifth Wheel Hitch - Max Tongue Wt.

367 - 726 kg

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Four-Wheel Drive

Transmission

6-speed manual transmission w/OD

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.8 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

Not Available

Rollover Protection Bars

Not Available

Child Safety Locks

Not Available

Emergency Trunk Release

Not Available

Driver Restriction Features

Not Available

Driver Assistance

Back-Up Camera

Not Available

360 Camera

Not Available

Brake Assist

Not Available

Blind Spot Monitor

Not Available

Lane Departure Warning

Not Available

Lane Keeping Assist

Not Available

Cross-Traffic Alert

Not Available

Rear Parking Aid

Included

Automatic Parking

Not Available

Tire Pressure Monitor

Not Available

Cruise Control

Included

Adaptive Cruise Control

Not Available

Heads-Up Display

Not Available

Lighting

Daytime Running Lights

Included

Automatic Headlights

Included

HID headlights

Not Available

Headlights-Auto-Leveling

Not Available

Night Vision

Not Available

Integrated Turn Signal Mirrors

Included

Auto-Dimming Rearview Mirror

Not Available

Infotainment

AM/FM Stereo

Included

HD Radio

Not Available

Satellite Radio

Not Available

CD Player

Included

MP3 Player

Optional

Auxiliary Audio Input

Not Available

Hard Disk Drive Media Storage

Not Available

Rear Seat Audio Controls

Not Available

Steering Wheel-Audio Controls

Not Available

Navigation System

Not Available

Connectivity

Smart Device Integration

Not Available

Apple CarPlay

Not Available

Android Auto

Not Available

WiFi Hotspot

Not Available

Bluetooth Connection

Not Available

Power Outlet

Included

Wireless Charging

Not Available

Comfort

Air Conditioning

Included

Climate Control

Not Available

Multi-Zone Air Conditioning

Not Available

Rear Air Conditioning

Not Available

Heated Front Seat(s)

Not Available

Heated Rear Seat(s)

Not Available

Cooled Front Seat(s)

Not Available

Cooled Rear Seat(s)

Not Available

Driver Adjustable Lumbar

Included

Passenger Adjustable Lumbar

Included

Seat-Massage

Not Available

Heated Steering Wheel

Not Available

Convenience

Power Windows

Included

Power Door Locks

Included

Keyless Entry

Included

Keyless Start

Not Available

Power Driver Seat

Included

Power Passenger Seat

Included

Seat Memory

Not Available

Power Mirror(s)

Included

Heated Mirrors

Included

Mirror Memory

Not Available

Power Folding Mirrors

Not Available

Power Liftgate

Not Available

Hands-Free Liftgate

Not Available

Remote Trunk Release

Not Available

Remote Engine Start

Not Available

Variable Speed Intermittent Wipers

Not Available

Rain Sensing Wipers

Not Available

Universal Garage Door Opener

Not Available

Running Boards/Side Steps

Included

Power Retractable Running Boards

Not Available

Interior

Passenger Capacity

5 - 6

Front Head Room

1,049 mm

Front Leg Room

1,041 mm

Front Shoulder Room

1,727 mm

Rear Head Room

1,036 mm

Rear Leg Room

1,059 mm

Rear Shoulder Room

1,727 mm

Trunk Volume

N/A

Front Reading Lamps

Included

Rear Reading Lamps

Included

Exterior

Wheelbase

4,379 mm

Length, Overall

N/A

Width, Max w/o mirrors

2,029 mm

Height, Overall

2,075 mm

Min Ground Clearance

N/A

Base Curb Weight

N/A

Front Tire Size

LT275/65R20E LT275/70R18E

Rear Tire Size

LT275/65R20E LT275/70R18E

Sun/Moon Roof

Included

Luggage Rack

Not Available

Stepside Pickup Box

Not Available

Bed Liner

Not Available

Canopy

Not Available

Pickup Bed Tonneau Cover

Not Available

Security

Security System

Not Available

Engine Immobilizer

Not Available

Wheels-Locks

Not Available

54 of 133

Crew Cab 172" XL

$35,999 MSRP

Gasoline, Diesel

Rear-Wheel Drive

325 - 362 horsepower

Show full trim specifications

Hide full trim specifications

Trim Specifications

Mechanical

Engine

Diesel V8 Gas V10

Displacement

6.0L/363 6.8L/415

Fuel System

Turbo-Charged DI EFI

Horsepower

325 hp @ 3300 rpm 362 hp @ 4750 rpm

Torque

570 ft-lb @ 2000 rpm 457 ft-lb @ 3250 rpm

Dead Weight Hitch - Max Trailer Wt.

8,709 kg

Dead Weight Hitch - Max Tongue Wt.

N/A

Wt Distributing Hitch - Max Trailer Wt.

N/A

Wt Distributing Hitch - Max Tongue Wt.

N/A

Fifth Wheel Hitch - Max Trailer Wt.

N/A

Fifth Wheel Hitch - Max Tongue Wt.

N/A

Maximum Trailering Capacity

N/A

Steering

Power Steering

Drivetrain

Rear-Wheel Drive

Transmission

6-speed manual transmission w/OD-inc: pwr take-off provision (PTO)

Fuel

Gasoline Diesel

Fuel Consumption: City

N/A

Fuel Consumption: Highway

N/A

Fuel Consumption: City/HWY Combined

N/A

Fuel Capacity

143.0 L

Safety

Driver Air Bag

Included

Passenger Air Bag

Included

Front Side Air Bag

Not Available

Rear Side Air Bag

Not Available

Front Head Air Bag

Not Available

Rear Head Air Bag

Not Available

Knee Air Bag

Not Available

Seatbelt Air Bag

Not Available

Brake

4 Wheel Disc

Brake ABS System

Included

Traction Control

Not Available

Stability Control

2006 Ford F-350

Key Specifications for 2006 Ford F-350

Review & Compare:
2006 Ford F-350 Trims

2006 Ford F-350

Key Specifications for 2006 Ford F-350

Review & Compare: 2006 Ford F-350 Trims

Review & Compare:
2006 Ford F-350 Trims
