Compare trims
Base
Ultra
Special
CVO Road Glide
MSRP
$26,599
$31,399
$32,899
$51,799
Type
Touring
Touring
Touring
Touring
Fuel Capacity
22.70 l (6 gal)
22.70 l (6 gal)
22.70 l (6 gal)
22.70 l (6 gal)
Luggage Capacity - Volume
2.30 cu ft
4.70 cu ft
2.70 cu ft
2.40 cu ft
Cooling
Oil
Liquid
Oil
Liquid
Ground Clearance
5.50 in (140 mm)
5.10 in (130 mm)
5.50 in (140 mm)
4.90 in (124.50 mm)
Height
51.60 in (1,310 mm)
56.10 in (1,425 mm)
51.60 in (1,310 mm)
-
Length
95.70 in (2,430 mm)
102.20 in (2,595 mm)
95.70 in (2,430 mm)
96.90 in (2,461.30 mm)
Seat Height
27.40 in (696 mm)
28.90 in (734.10 mm)
27.40 in (696 mm)
26.80 in (680.70 mm)
Wheelbase
64 in (1,625 mm)
64 in (1,625 mm)
64 in (1,625 mm)
64 in (1,625.60 mm)
Width
38.60 in (980 mm)
36.60 in (930 mm)
38.60 in (980 mm)
-
Gear Ratios
9.59 / 6.65 / 4.94 / 4 / 3.41 / 2.88
9.59 / 6.65 / 4.94 / 4 / 3.41 / 2.88
9.59 / 6.65 / 4.94 / 4 / 3.41 / 2.88
9.59 / 6.65 / 4.94 / 4 / 3.41 / 2.88
Primary Drive
Chain , Belt
Chain , Belt
Chain , Belt
Chain , Belt
Bore
3.94 in (100.10 mm)
3.94 in (100.10 mm)
3.94 in (100.10 mm)
4.08 in (103.70 mm)
Carburetor
Fuel Injected
Fuel Injected
Fuel Injected
Fuel Injected
Compression Ratio
10.0:1
10.0:1
10.0:1
10.2:1
Cylinders
2
2
2
2
Displacement
1,753.40 cc
1,753.40 cc
1,753.40 cc
1,917.30 cc
Engine Brand Name
Milwaukee-Eight 107
Twin-Cooled Milwaukee-Eight 107
Milwaukee-Eight 107
Twin-Cooled Milwaukee-Eight 117
Engine Type
V Twin
V Twin
V Twin
V Twin
Stroke
4.38 in (111.30 mm)
4.38 in (111.30 mm)
4.38 in (111.30 mm)
4.50 in (114.30 mm)
Engine Torque
150.50 Nm
154.60 Nm
150.50 Nm
169.50 Nm
Engine Torque (rpm)
3,250 rpm
3,250 rpm
3,250 rpm
3,500 rpm
Fuel Economy: Combined City/Hwy
5.20 L/100km
5.50 L/100km
5.20 L/100km
5.70 L/100km
Transmission
6 speed / Manual
6 speed / Manual
6 speed / Manual
6 speed / Manual
Weight As Shipped
820 lbs (372 kg)
899 lbs (407.80 kg)
820 lbs (372 kg)
849 lbs (385.10 kg)
Weight In Running Order
855 lbs (388 kg)
937 lbs (425 kg)
855 lbs (388 kg)
884 lbs (401 kg)
Tires Front Specification
Dunlop Dunlop Multi-Tread 130/60 R19 61H
Dunlop Dunlop Multi-Tread 130/80 R17 65H
Dunlop Dunlop Multi-Tread 130/60 R19 61H
Dunlop Dunlop Multi-Tread 130/60 R21 63H
Tires Rear Specification
Dunlop Dunlop Multi-Tread 180/65 R16 81H
Dunlop Dunlop Multi-Tread 180/65 R16 81H
Dunlop Dunlop Multi-Tread 180/55 R18 80H
Dunlop Dunlop Multi-Tread 180/55 R18 80H
