Specifications
Base
MSRP
-
Type
Touring
Front Braking System
Dual Disc / 292.10 mm
Rear Braking System
Disc / 292.10 mm
Fuel Capacity
22.70 l (6 gal)
Cooling
Air
Ground Clearance
5.10 in (129.50 mm)
Length
93.70 in (2,380 mm)
Seat Height
26.90 in (683.30 mm)
Wheelbase
63.50 in (1,612.90 mm)
Gear Ratios
9.31 / 6.42 / 4.77 / 3.93 / 3.28 / 2.79
Primary Drive
Chain , Belt
Bore
3.75 in (95.30 mm)
Carburetor
Fuel Injected
Compression Ratio
9.2:1
Cylinders
2
Displacement
1,584 cc
Engine Brand Name
Twin Cam 96
Engine Type
V Twin
Stroke
4.38 in (111.30 mm)
Engine Torque
125.50 Nm
Engine Torque (rpm)
3,500 rpm
Transmission
6 speed / Manual
Weight As Shipped
752 lbs (341.10 kg)
Weight In Running Order
789 lbs (357.90 kg)
Tires Front Specification
Dunlop Dunlop MT90B16 72H
Tires Rear Specification
Dunlop Dunlop MU85B16 77H
